N-BM160W


Product Highlights :-

Face Capacity
2000
Fingerprint Capacity
3000
Max. user
3000
Log Capacity
1,50,000
Password capacity
3000
Card capacity
3000

Technical Specification

Multi-Biometric Time Attendance & Access  Control System

Storage capacity

Face Capacity
2000


Fingerprint Capacity

3000

Max. User

3000

Log Capacity

1,50,000

Password Capacity

3000


Card capacity

3000


CPU

1GHz

Biometric

FAR

0.00001%


FRR

0.001%


Sensor type

500 DPI


GPRS

Optional


Identification Mode

Face, Fingerprint, Card, PIN

RF card options

125kHz EM (Standard) / 13.56MHz Mifare (Optional)

Audio/Visual

LCD

2.4" TFT color screen 320x240 pixel


Voice instruction

16-bit Hi-Fi voice & sound indication


Language

English

Communication

Communication

WIFI, TCP/IP, RS232/485, USB (host and slave)


Push data

Yes

Power & environment

Built-in backup Battery

Yes


Power

12VDC/2A


Operating Temperature

0°c - 45°c


Dimension

160 x 150 x 65 mm

Access control

Wiegand in & out

Yes


Relay

Yes

Software

Attendance Software

Yes

Features

World-class algorithm


High-Speed and Accurate Identification


Face, Fingerprint, Pin, Card authentication


Self-Service Inquiry
